    107702
    BGN7,124.94
    • Perfect for uniform board production or frame making
    • 4 row Spiral cutter block with 52 TCT indexing cutters
    • Large table with support rollers, fitted with digital height gauge

    Description

    When it comes to producing timber to a uniform thickness, with parallel faces and edges, a thicknesser is unbeatable. The AP310T2 has power and strength in abundance with a cast iron frame and table, supported on a sturdy steel base. Power comes from a 2.2kW induction motor. The long 930mm long table has additional support rollers at each end. A digital height gauge aids accurate setting. By far, the machine’s best feature is the spiral cutter block. Four rows of TC cutters, give an almost perfect finish. The cutters are arranged to produce a super clean shear cut. With each cutter having four edges you can simply turn to a fresh edge when required. If one or more cutters are damaged, then simply replace it. Each edge lasts up to 10 times longer than that of an HSS blade, greatly reducing downtime. There is no setting, saving more time and guaranteeing accuracy. The combination of the angled cutter and curved edge is much kinder on the timber, even heavily figured timber presents no issues with tear-out. The other main benefits of this type of cutter block: much lower noise, and much reduced power required to drive it. The waste chips are much more uniform, being easier to extract and packing more into your extractor's waste container. This solidly built, relatively compact machine is capable of handling quite large board runs or sizing frames or beams. N.B. This Machine requires a 16amp supply and it's recommended that a C Type breaker is used, if you are unsure please contact a qualified electrician.

    Product Details

    Max Thicknessing Width
    310 mm
    Overall L x W x H
    1,050 mm x 610 mm x 1,020 mm
    Knives
    TC Spur Cutters x 52
    Dust Extraction Outlet
    125 mm
    Plug Fitted
    UK 16A Plug
    Power
    2.2 kW
    Feed Speed
    6 m/min
    Nett Weight
    200 kg
    Rating
    Trade/Professional
    Min Extraction Airflow Required
    1,300 m³/hr
    Cutterblock Speed
    4,050 rpm
    Cuts per Minute
    16,000
    Cutterblock Diameter
    95 mm
    Length of Table
    930 mm
    Max Depth of Cut Thicknesser
    3.0 mm
    Max Thicknessing Height
    310 mm
    Min Thicknessing Height
    5.0 mm
    Sound Pressure Level LpA [Uncertainty K]
    84 dB(A) [2.0 dB]
    Voltage
    230 V
